MONDRAKER Raze 2024

Detailní popis produktu

•

  Rám

  Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05



  Velikosti

  S: 380mm / M: 420mm / L: 470mm / XL: 510mm

•

  Tlumič


  Fox Float EVOL Performance, 205x57.5mm. Settings: 2-position compression adjustment (Open/Firm), rebound, air preload. Trunnion top mount, 25x8mm bottom bushings



  Shock settings

  Light compression, light rebound, air volume spacer 0.6

•

  Vidlice

  RockShox 35 Gold 29 RL, 150mm, Solo Air, tapered steerer tube, Boost 15x110mm axle, 35mm steel stanchions, 44mm offset. Settings: compression adjustment at low-speed to lock, rebound, air preload



  H.složení

  Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

• Představec

  Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore



  Řídítka

  Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

•

  Gripy

  Onoff Twin, 1lock-on, 135mm



  Sedlovka

  Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm

•

  Sedlo

  Mondraker MDK Series, SRX, steel rail



  P.brzda

  Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad

•

  Z.brzda

  Sram Level T, 2 piece caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pad



  B.páky

  Sram Level T, Direct Link actuation, tooled reach adjust, lever pivot bushings

•

  Ráfek

  Mavic CrossRide 29 Boost, 30mm internal width, tubeless ready, 28 spokes



  Výplet

  Mavic 28 round j-bend stainless steel

•

  P.náboj

  Mavic Boost 15x110mm, sealed bearings, IS 6 bolts



  Z.náboj

  Mavic ID360 freewheel technology, Boost 12x148mm, IS 6 bolts, HG freehub

•

  P.pneu

  Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead



  Z.pneu

  Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead

•

  Kliky

  Sram SX Eagle, Boost, DUB axle, Direct Mount chain ring, S size: 170mm M size: 170mm L size: 175mm XL size: 175mm, CL 52



  převodník

  32T, steel, X-Sync 2

• středové složení


  Sram DUB BSA, sealed bearings, 73mm



  řetěz

  Sram SX Eagle, 12s, Powerlock

•

  Přehazovačka

  Sram SX Eagle, Type 3 roller bearing clutch, cage lock, long cage, 1x12s, X-actuation 1:1



  Řazení

  Sram Trigger SX Eagle, 12s, X-Actuation 1:1

•

  Kazeta

  Sram PG-1210, 11-50T, 12s



  Patka

  Sram UDH
