MONDRAKER Raze R 2024

Kód: 40369/XL 40369/M 40369/L 40369/S Zvolte variantu
Novinka
Neohodnoceno
Značka: Mondraker
95 990 Kč –18 %
1701087343 2600 6564886f45e66427578857 raze r
95 990 Kč –18 % 77 990 Kč
na dotaz na dotaz Skladem/ nebo do 2 dnů na dotaz Zvolte variantu
Velikost
Zvolená varianta není k dispozici. Reset vybraných parametrů.
Můžeme doručit do:
- - 4.12.2024 - Zvolte variantu



  • frame

    Frame

    Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05

    sizes

    Sizes

    S: 380mm / M: 420mm / L: 470mm / XL: 510mm

  • rear shock

    Rear shock

    Fox Float EVOL Performance, 205x57.5mm. Settings: 2-position compression adjustment (Open/Firm), rebound, air preload. Trunnion top mount, 25x8mm bottom bushings

    shock settings

    Shock settings

    Light compression, light rebound, air volume spacer 0.6

  • fork

    Fork

    Fox 36 29 Float GRIP EVOL Rhythm, 150mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload

    headset

    Headset

    Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

  • stem

    Stem

    Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

    handlebar

    Handlebar

    Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

  • grips

    Grips

    Onoff Twin, 1lock-on, 135mm

    seatpost

    Seatpost

    Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm

  • saddle

    Saddle

    Mondraker MDK Series, SRX, steel rail

    front brake

    Front brake

    Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

  • rear brake

    Rear brake

    Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

    brake lever

    Brake lever

    Sram G2 R, tool-free reach adjust, lever pivot bushings

  • rims

    Rims

    Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes

    spokes

    Spokes

    Mavic 24 straight-pull double butted spokes

  • front hub

    Front hub

    Mavic Infinity hub, Boost 15x110mm, IS 6 bolts

    rear hub

    Rear hub

    Mavic Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts, HG freehub

  • front tire

    Front tire

    Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

    rear tire

    Rear tire

    Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead

  • crankset

    Crankset

    Truvativ Stylo 7k Eagle, Boost, DUB axle, Direct mount chain ring, S size: 170mm M size: 170mm L size: 175mm XL size: 175mm, CL 52

    rings

    Rings

    32T, CNC-machined alloy, X-SYNC 2

  • bottom bracket

    Bottom bracket

    Sram DUB BSA, sealed bearings, 73mm

    chain

    Chain

    Sram NX Eagle, 12s, Powerlock

  • rear derrailleur

    Rear derrailleur

    Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

    shift levers

    Shift levers

    Sram Trigger NX Eagle, 12s, X-Actuation 1:1

  • casette

    Casette

    Sram PG-1230, 11-50T, 12s

    derailleur hanger

    Derailleur hanger

    Sram UDH



Detailní informace

Detailní popis produktu



  • frame

    Rám

    Raze 29 6061 Alloy Stealth Evo, hydroformed tubing, Zero Suspension System, 130mm travel, Forward Geometry, one piece Monoblock upper link, Boost 12x148mm rear axle, tapered head tube, 73mm BSA bottom bracket, dedicated 1x drivetrain design, telescopic seatpost internal routing, MAX capacity sealed bearings, ISCG 05

    sizes

    Velikosti

    S: 380mm / M: 420mm / L: 470mm / XL: 510mm

  • rear shock

    Tlumič

    Fox Float EVOL Performance, 205x57.5mm. Settings: 2-position compression adjustment (Open/Firm), rebound, air preload. Trunnion top mount, 25x8mm bottom bushings

    shock settings



    Light compression, light rebound, air volume spacer 0.6

  • fork

    Vidlice

    Fox 36 29 Float GRIP EVOL Rhythm, 150mm, tapered steerer tube, Boost 15x110mm axle, offset 44mm. Settings: sweep adjust compression, low-speed rebound, air preload

    headset

    H.složení

    Onoff Saturn tapered for 1-1/8” to 1-1/2” head tube, ACB sealed bearings, top 41x30.2x7x45ºx45º, bottom 51.9x40x8x45ºx45º

  • stem

    Představec

    Onoff Sulfur FG 30mm 0º, 6061 forged alloy, 31.8mm barbore

    handlebar

    Řídítka

    Onoff Sulfur 1.0 double butted 6061 alloy, rise: 20mm, width: 800mm, 9º backsweep, 5º upsweep, 31.8mm barbore

  • grips

    Gripy

    Onoff Twin, 1lock-on, 135mm

    seatpost

    Sedlovka

    Onoff Pija dropper internal, diameter 31.6mm, 1X Remote lever with bearing, S size: 405x95-125mm, M size: 458x120-150mm, L size: 498x140-170mm, XL size: 558x170-200mm

  • saddle

    Sedlo

    Mondraker MDK Series, SRX, steel rail

    front brake

    P.brzda

    Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

  • rear brake

    Z.brzda

    Sram G2 R, 4-piston caliper, Centerline 180mm IS 6 bolts one-piece rotor, steel-backed organic pads

    brake lever

    B.páky

    Sram G2 R, tool-free reach adjust, lever pivot bushings

  • rims

    Ráfky

    Mavic CrossMax XL S, 29 Boost 30mm internal width, hookless, tubeless ready, 24 spokes

    spokes

    Dráty

    Mavic 24 straight-pull double butted spokes

  • front hub

    P.náboj

    Mavic Infinity hub, Boost 15x110mm, IS 6 bolts

    rear hub

    Z.náboj

    Mavic Infinity hub, ID360 freewheel technology, Boost 12x148mm, IS 6 bolts, HG freehub

  • front tire

    P.plášť

    Maxxis Dissector 29x2.4 WT, tubeless ready, 3C MAXX TERRA compound, EXO+ protection, 120TPI, folding bead

    rear tire

    Z.plášť

    Maxxis Aggressor 29x2.3, tubeless ready, dual compound, Exo protection, 60TPI, folding bead

  • crankset

    Kliky

    Truvativ Stylo 7k Eagle, Boost, DUB axle, Direct mount chain ring, S size: 170mm M size: 170mm L size: 175mm XL size: 175mm, CL 52

    rings

    Převodník

    32T, CNC-machined alloy, X-SYNC 2

  • bottom bracket

    Stř.složení

    Sram DUB BSA, sealed bearings, 73mm

    chain

    Řetěz

    Sram NX Eagle, 12s, Powerlock

  • rear derrailleur

    Přehazovačka

    Sram GX Eagle, Type 3 roller bearing clutch, cage lock, 1x12s, X-Actuation 1:1

    shift levers

    Řazení

    Sram Trigger NX Eagle, 12s, X-Actuation 1:1

  • casette

    Kazeta

    Sram PG-1230, 11-50T, 12s

    derailleur hanger

    Patka

    Sram UDH
